Descripción
| SWITCH | TIPO | SWITCH BASICO ADMINISTRABLE | |
| MARCA | RUCKUS | ||
| MODELO | ICX 7150-C12P | ||
| CARACTERISTICAS DE HARDWARE | PUERTOS | RJ-45 | 12 x 10/100/1000 MB/S (GbE) 2 x 10/100/100 MB/S (GbE) UPLINK |
| SFP+ | 2 x 1/10 GbE | ||
| LOS 12 PUERTOS RJ-45 SON PoE+ | |||
| ESTANDARES | IEEE 802.1AB IEEE 802.1D IEEE 802.1p IEEE 802.1s IEEE 802.1w IEEE 802.1x IEEE 802.3 IEEE 802.3ab IEEE 802.3 IEEE 802.3ad IEEE 802.1 IEEE 802.3ae IEEE 802.3af IEEE 802.3at IEEE 802.3u IEEE 802.3x IEEE 802.3z IEEE 802.3 IEEE 802.3az IEEE 802.1Q IEEE 802.1BR |
||
| USB | 1 x USB (TIPO A) | ||
| CONSOLA | 1 x RJ-45 | ||
| ADMINISTRACION | 1 x RJ-45 10/100/1000 MB/S | ||
| RENDIMIENTO | MEMORIA | DRAM 1GB NVRAM FLASH: 2GB |
|
| BUFFER | 2MB | ||
| CAPACIDAD SWITCHING | 68 GB/S | ||
| RENDIMIENTO | 51 MP/S | ||
| TABLA DE DIRECCIONES MAC | 16 384 | ||
| ADMINISTRACION Y CONFIGURACION | ADMINISTRACION: DHCP AUTO CONFIGURATION CONFIGURATION LOGGING DIGITAL OPTICAL MONITORING DISPLAY LOG MESSAGES ON MULTIPLE TERMINALS EMBEDDED WEB MANAGEMENT (HTTP/HTTPS) EMBEDDED DHCP SERVER INDUSTRY-STANDARD COMMAND LINE INTERFACE (CLI) BROCADE NETWORK ADVISOR (SOLD SEPARATELY) CLI ACTIVATION OF OPTIONAL SOFTWARE FEATURES |
||
| INTEGRATION WITH HP OPENVIEW: USB FILE MANAGEMENT AND STORAGE MACRO FOR BATCH EXECUTION OUT-OF-BAND ETHERNET MANAGEMENT TFTP TELNET CLIENT AND SERVER BOOTP SNMPV1/V2C DHCP SERVER AND DHCP RELAY SNMPV3 INTRO TO FRAMEWORK ARCHITECTURE FOR DESCRIBING SNMP FRAMEWORK |
|||
| SNMP MESSAGE PROCESSING AND DISPATCHING SNMPV3 APPLICATIONS SNMPV3 USER-BASED SECURITY MODEL SNMP VIEW-BASED ACCESS CONTROL MODEL SNMP SFLOW NETWORK TIME PROTOCOL (NTP) MULTIPLE SYSLOG SERVERS SCP VIRTUAL CABLE TESTER (VCT) |
|||
| CAPA 2 | |||
| 802.1S MULTIPLE SPANNING TREE 802.1X AUTHENTICATION AUTO MDI/MDIX BPDU GUARD, ROOT GUARD DUAL-MODE VLANS MAC-BASED VLANS, DYNAMIC MAC-BASED VLAN ACTIVATION DYNAMIC VLAN ASSIGNMENT DYNAMIC VOICE VLAN ASSIGNMENT FAST PORT SPAN GVRP: GARP VLAN REGISTRATION PROTOCOL IGMP SNOOPING (V1/V2/V3) IGMP PROXY FOR STATIC GROUPS IGMP V2/V3 FAST LEAVE INTER-PACKET GAP (IPG) ADJUSTMENT |
|||
| LINK FAULT SIGNALING (LFS) MAC ADDRESS FILTERING MAC LEARNING DISABLE MLD SNOOPING (V1/V2) MULTI-DEVICE AUTHENTICATION PER-VLAN SPANNING TREE (PVST/PVST+/PRST) MIRRORING: PORT-BASED, ACL-BASED, MAC FILTER-BASED, AND VLAN-BASED PIM-SM V2 SNOOPING PORT LOOP DETECTION PRIVATE VLAN REMOTE FAULT NOTIFICATION (RFN) SINGLE-INSTANCE SPANNING TREE SINGLE-LINK LACP TRUNK GROUPS (STATIC, LACP) |
|||
| UNI-DIRECTIONAL LINK DETECTION (UDLD) METRO-RING PROTOCOL (MRP) (V1, V2) VIRTUAL SWITCH REDUNDANCY PROTOCOL (VSRP) VLAN STACKING (Q-IN-Q) TOPOLOGY GROUPS |
|||
| CAPA 3 | |||
| IPV4 AND IPV6 STATIC ROUTES RIP V1/V2, RIPNG ECMP PORT-BASED ACCESS CONTROL LISTS LAYER 3/LAYER 4 ACLS |
|||
| HOST ROUTES VIRTUAL INTERFACES ROUTED INTERFACES ROUTE-ONLY SUPPORT ROUTING BETWEEN DIRECTLY CONNECTED SUBNETS |
|||
| SEGURIDAD | 802.1X AUTHENTICATION MAC AUTHENTICATION FLEXIBLE AUTHENTICATION WEB AUTHENTICATION DHCP SNOOPING DYNAMIC ARP INSPECTION NEIGHBOR DISCOVERY (ND) INSPECTION BI-LEVEL ACCESS MODE (STANDARD AND EXEC LEVEL) |
||
| EAP PASS-THROUGH SUPPORT IEEE 802.1X USERNAME EXPORT IN SFLOW PROTECTION AGAINST DENIAL OF SERVICE (DOS) ATTACKS AUTHENTICATION, AUTHORIZATION, AND ACCOUNTING (AAA) MAC ADDRESS LOCKING MAC PORT SECURITY ADVANCED ENCRYPTION STANDARD (AES) WITH SSHV2 |
|||
| RADIUS/TACACS/TACACS+ SECURE COPY (SCP) SECURE SHELL (SSHV2) LOCAL USERNAME/PASSWORD CHANGE OF AUTHORIZATION (COA) RFC 5176 TRUSTED PLATFORM MODULE |
|||
| ALIMENTACION Y ENERGIA | TIPO DE FUENTE DE ALIMENTACION | INTERNA | |
| VOLTAJE DE ALIMENTACION | AUTOVOLTAJE (100V ~ 240 VAC) | ||
| ALIMENTACION POE | 124 W | ||
| CARACTERISTICAS FISICAS | DIMENSIONES | 4.34 x 26.90 x 21.30 CM | |
| PESO | 2.58 KG | ||
| CONDICIONES AMBIENTALES | TEMPERATURA | OPERACION | -5° C HASTA 45° C |
| ALMACENAJE | -25° C HASTA 70° C | ||
| HUMEDAD | OPERACION | 5% HASTA 95% (SIN CONDENSACION) | |
| ALMACENAJE | 0% HASTA 95% (SIN CONDENSACION) | ||
