Descripción
| Rango de Frecuencia | 2.3 – 2.6 GHz |
| Ganancia | 17.3-18.2 dBi |
| Polarización | Dual Lineal |
| Aislamiento de Polarización | 28dB min. |
| Max VSWR | 1.5:1 |
| Angulo de Ancho de Onda | 60°/ 90°/ 120° . |
| Viento Loading | 92 lbs @ 100 mph |
| Cross-Pol Isolation | 25 dB Typical |
| Downtilt Eléctrico | 4° |
| Front-to-Back Ratio | 30 dB |
| RF Connectors | 2 SMA Connectors (Weatherproof ) |
| Compatible Radios | RocketM2 Titanium |
| RocketM2 | |
| Mounting | Pole Mount (Kit Included) |
| Especificación ETSI | EN 302 326 DN2 |
| Dimensiones | 773 x 372 x 120 mm |
| Peso | 6.40 kg |
| Resistencia al viento | 125 mph |
| Certifications | CE, FCC, IC |
